A Next Generation Sampling Comparator Probe for the NIST Sampling Waveform Analyzer
Format: Paperback
ISBN13: 9781494743857
Paperback|9781494743857
✨ Featured Offer
Brand New
$18.00
List Price: $15.99
🚚
See all 2 offers from $18.00 FREE standard delivery by: 01 Apr 2026
Overview
The design and performance of a Next Generation Sampling Comparator Probe (NGSCP) is described. It is intended as one of a group of probes designed for use with the NIST Sampling Waveform Analyzer (SWA). The probe design is centered on an application specific integrated circuit (ASIC) analog comparator featuring a bandwidth of 6 GHz. The design considerations of the ASIC analog comparator and the probe are discussed. The probe's performance features are compared against a previously designed ASIC probe. In addition to the design aspects of the probe, a thermal error correction technique is described which shows how high-speed settling performance can be enhanced. This technical note provides complete schematic diagrams of the ASIC comparator and the probe.
